Rd50 - Rdh50 Test Kiln (R12125)

5.0
Brand : REFSAN
Discount Rate : %12 Discount
Price : 3.240,00€
Discounted : 2.850,00€
Barkod : 8681910649033
Add to Favorites
Add to Collection
Add to my Wish List
Compare
Notify me when the price goes down
Notify me when it is in stock
Write a comment
Questions and Answers
Refsan Logo

RD50 Test Kiln

Large-Capacity Test Kiln for R&D, Recipe Testing and Sample Firing

RD50 Large Capacity, Controlled Test Firings

The RD50 Test Kiln is a large-capacity chamber kiln developed for new product development, recipe testing, R&D studies and sample firing. It can be safely preferred for test work requiring higher capacity in the ceramic, porcelain, glass, enamel, laboratory and technical material industries.

With 1200°C and 1320°C maximum temperature options, it allows temperature, color, strength and process tests to be performed on samples before production. This enables results to be verified safely and economically before moving to large-scale production.

RD50 Test Kiln
Kanthal A1 Resistance System

Powerful Insulation for Test Firings

The high-density alumina bricks resistant up to 1430°C used inside the RD50 help keep heat evenly balanced inside the kiln during test firings. Its strong insulation structure improves energy efficiency, while its fiber-free design provides a safer working environment for laboratories, workshops and R&D facilities.

RD50 Test Kiln Technical Structure

RD50 combines its large internal volume with professional control systems to deliver reliable performance in recipe testing, sample firing and R&D studies. It enables controlled evaluation of temperature, color, strength and process results during pre-production trials.

Digital Program Control

With the RF860 programmer, temperature increase, holding time and test firing steps are managed in a controlled way.

Precise Temperature Measurement

The thermocouple system monitors the internal kiln temperature and helps achieve repeatable results in sample firings.

Alumina Brick Insulation

The brick structure resistant up to 1430°C keeps heat balanced inside the chamber and provides a reliable test firing environment.

Kanthal A1 Resistance

Supports balanced temperature, color and strength results in sample studies by providing homogeneous heat distribution.

RD50 test kiln technical usage image

What Is the RD50 Test Kiln Ideal For?

Recipe Testing

Allows color, surface, strength and temperature results in ceramic, porcelain, glass and enamel recipes to be tested before production.

R&D Studies

Provides a safe and controlled working environment for samples in new product development and technical material trials.

Workshop and Production

Helps verify process results economically and repeatedly before moving to large-scale production.

Monitor Your Kiln Processes from Anywhere

Thanks to SuperWise technology, you can instantly monitor your kiln’s temperature data and test firing process from your mobile device. This gives you greater control over recipe testing, sample firing and R&D studies while helping save time.

✓ Real-Time Temperature Monitoring
✓ Test Firing Control
✓ Power and Voltage Analysis
✓ End-of-Process Notification
Standard equipment includes the REFSAN RF860 programmer. WiFi-supported TC75, TC95 and TX95 options are optional.
SuperWise Mobile App

Safe and Controlled Test Firings

A reliable working environment supported by professional safety systems

100% Fiber-Free

100% Fiber-Free

Healthy insulation structure that does not contain fiber-based materials.

Door Switch Safety

Door Safety

Safety support for front-loading operation.

Smart Monitoring System

Smart Monitoring

A system that helps manage the test firing process in a controlled way.

Technical Specifications

RD27, RD50 and RS80 test kilns serve the same purpose in recipe testing, R&D studies and sample firing. The main differences between the models are internal volume, capacity and size options.

Features
RD 27 RD 27
RD 50 RD 50
RS 80 RS 80
Volume
27 L
50 L
80 L
Power Supply
230V
230V
230V - 400V
Insulation Type
European Alumina Brick
European Alumina Brick
European Alumina Brick
Heating Surfaces
2-Sided (Right - Left)
2-Sided (Right - Left)
3-Sided (Right - Left - Bottom)
Control Unit
Digital Programmer
Digital Programmer
Digital Programmer
Internal Dimensions (WxDxH)
30x30x30cm
35x35x40cm
40x40x50cm
External Dimensions (WxDxH)
70x65x80cm
70x80x85cm
80x80x125cm
Power
5.5 kW
6 kW
8 kW
Average Mug Capacity
Approx. 14 pcs
Approx. 30 pcs
Approx. 68 pcs
Weight
Approx. 136 kg
Approx. 165 kg
Approx. 260 kg
WiFi Kilns Industrial Logo

Programmer Options

Features
REFSAN RF860
TC75
TC95
TX95
Display Type Digital, 9-line information display LED 2.8-inch TFT Color 4.1-inch High Resolution
Program / Step Count 5 Programs / 15 Sets 6 Programs / 4 Steps 20 Programs / 20 Steps 100 Programs / 50 Steps
WiFi & Remote Monitoring - Available Available Available
Power and Voltage Monitoring - - - Available (Smart Analysis)
Detailed Kiln Analysis Last 8 reports Available Available Available
The RD50 test kiln includes the REFSAN RF860 programmer as standard equipment. TC75, TC95 and TX95 options are optional for WiFi features.

"Refsan has been producing high temperature kilns and laboratory furnaces for professional industrial applications for many years"

Model
RD50
Kiln Type
CHAMBER KILNS (FRONT LOADING)
Volume
50 LT.
Maximum Temperature
1200°C
Outer Dimensions (WxDxH)
70x80x85cm
Inner Dimensions (WxDxH)
35x35x40cm
Weight
165 kg
Phase
Single-phase
Power
230V
Cable Thickness - Fuse
Requirements for 230V RS Model; Cable Thickness 3X4 - Fuse (Amps) 1X32
Connected Load kW
6kW
Thermocouple
K TYPE ( 0 - 1200 °C)
Insulation Type
EUROPEAN ALUMINA BRICKS RESISTANT TO 1430°C
Heating Type
ELECTRIC RESISTANCES KANTHAL A1
Contact Type
SSR
Heating Sides
2 SIDES (LEFT+RIGHT)
Paint of Kiln
Electrostatic Powder Dye
Door Lock
AVAILABLE
Wheels
AVAILABLE
Protection Switch
AVAILABLE
Ceramic Fiber
N/A
Control Unit
DIGITAL PROGRAMMER (5 PROGRAM + 15 STEPS)
Operation Reports
Available / Last 8 Operation
Automatically Continuation After Power Cut
AVAILABLE
Automatically Start-up on Any Desired Time
AVAILABLE
Product Origin
TÜRKİYE
CE Certification
CERTIFIED
Competence of After Sale Services
AVAILABLE
ISO9001 Certificate
AVAILABLE
Warranty
2 YEARS
Service Support
10 YEARS
Accessories (Optional)
Refractory Kiln Shelf Refractory Prop Product Setter
Kiln Shelves (Optional)
30*30 cm
