Bowl Plaster Mold Series
A series of single-piece plaster casting molds designed for producing ceramic bowls in different sizes. With 5 different diameter options, it allows the production of various forms ranging from small serving bowls to larger service bowls. The molds can be used with earthenware, ceramic, stoneware, and porcelain casting slips.
30 cm Bowl
Finished Product Diameter 30 cm
Mold Width 45 cm
Mold Height 14,5 cm
25 cm Bowl
Finished Product Diameter 25 cm
Mold Width 45 cm
Mold Height 14,5 cm
20 cm Bowl
Finished Product Diameter 20 cm
Mold Width 30 cm
Mold Height 13,5 cm
15 cm Bowl
Finished Product Diameter 15 cm
Mold Width 30 cm
Mold Height 13,5 cm
5 cm Bowl
Finished Product Diameter 5 cm
Mold Width 20 cm
Mold Height 8 cm
Size Options 5 Different Sizes
Finished Product Diameters 5 / 15 / 20 / 25 / 30 cm
Number of Mold Pieces 1 Piece
Production Method Slip Casting
Dimension Information: The specified 5, 15, 20, 25, and 30 cm values refer to the diameters of the ceramic bisque pieces produced from the molds. Final product dimensions may vary depending on the shrinkage rate of the clay and the firing temperature.
Compatible Clays
The molds can be used with earthenware, ceramic, stoneware, and porcelain casting slips. The wall thickness and casting time may vary depending on the characteristics of the clay used.
A fuller wall thickness is generally preferred with ceramic and earthenware casting slips. Stoneware and porcelain casting slips, when used with suitable formulations and casting conditions, are suitable for producing thinner forms. With suitable porcelain bodies in particular, very thin castings with light-transmitting translucency can be achieved.
Warning: Not suitable for stone powder, plaster, concrete, resin, or similar non-ceramic casting materials.
Usage and Drying
- The casting slip should be poured into the mold in a controlled manner.
- It is recommended to mix the casting slip thoroughly until homogeneous before casting.
- Depending on ventilation and drying conditions, an average of 2–4 castings can be made per day.
- The mold should be allowed to dry sufficiently between castings.
Wet Mold Warning: Depending on production intensity, the mold may occasionally be shipped while still damp or wet. In this case, it should be left to air-dry naturally for 1–2 days in a well-ventilated area before use.
Minor deformation may occur on the outer surface, edges, or corners of the mold during transportation. The mold can still be used as long as there is no damage to the internal casting surface that would affect the finished product or interfere with the casting process.
Mold Lifespan: Approximately 100 castings on average. This may vary depending on the clay used, casting frequency, drying conditions, and method of use.
