BTH Andromeda DD03 Pottery Wheel
BTH Andromeda DD03 Pottery Wheel

BTH Andromeda DD03 Pottery Wheel (R24396)

5.0
Brand : BTH
Discount Rate : %9 Discount
Price : 2.080,00€
Discounted : 1.900,00€
Barkod : 8681910633957
Add to Favorites
Add to Collection
Add to my Wish List
Compare
Notify me when the price goes down
Notify me when it is in stock
Write a comment
Questions and Answers
BTH Andromeda DD03 Pottery Wheel
BTH

BTH Andromeda DD03 Pottery Wheel

60 kg clay capacity, direct drive motor, precise pedal control, and 5-year warranty

Powerful Torque, Quiet and Controlled Operation

BTH Andromeda DD03 Pottery Wheel is a powerful pottery wheel designed for professional ceramic production and intensive studio use, featuring a 60 kg clay capacity, 0–300 rpm wheel head speed, and 400 W motor power.

Direct drive motor technology transfers motor power directly to the wheel head system, providing balanced and controlled rotation. With an operating noise level of ≤40 dB, it creates a quieter and more comfortable working environment during extended wheel-throwing sessions.

Andromeda DD03 is supplied with a 5-year warranty. Its professional-use-oriented design has been developed for long-term studio work.

BTH Andromeda DD03 pottery wheel
BTH Andromeda DD03 pottery wheel in use

Direct Drive Motor and Precise Speed Control

The direct drive motor system used in the Andromeda DD03 transfers motor power directly to the wheel head system without requiring a belt and pulley mechanism. This design provides smoother and more stable rotation while also reducing mechanical maintenance requirements.

The modular foot pedal with Hall Effect technology enables precise control of speed changes. The wide 0–300 rpm speed range and clockwise/counterclockwise rotation capability accommodate different shaping techniques and user preferences.

Technical Design of the Andromeda DD03 Pottery Wheel

The Andromeda DD03 combines a direct drive motor, high clay capacity, Hall Effect pedal system, and magnetic splash pan with an ergonomic body design.

Direct Drive Motor

The direct drive system, which does not use a belt or pulley mechanism, transfers motor power directly to the wheel head system.

60 kg Clay Capacity

Its high centering capacity allows large and heavy ceramic forms to be worked on the wheel in a controlled manner.

Hall Effect Foot Pedal

The pedal system with contactless sensor technology helps detect even small pedal movements with precision.

Magnetic Splash Pan

The magnetic splash pan can be easily removed and reattached, making cleaning after use easier.

BTH Andromeda DD03 pottery wheel in use in a professional studio

What Is the Andromeda DD03 Suitable For?

Professional Ceramic Studios

With its 60 kg clay capacity, large wheel head, and direct drive motor system, it is suitable for ceramic studios engaged in regular and intensive production.

Educational Institutions and Courses

With its ≤40 dB quiet operating level, precise speed control, and bidirectional rotation system, it can be used in educational and course environments.

Large-Form Work

With its 35.2 cm aluminum wheel head and 60 kg clay capacity, it is suitable for working on large vases, bowls, and various ceramic forms.

Technical Specifications and Model Comparison

The BTH Andromeda DD03 is designed for professional ceramic production with its 60 kg clay capacity, 400 W motor power, 0–300 rpm speed range, Direct Drive system, Hall Effect pedal control, and 5-year warranty. You can compare its key technical specifications with the Sirius BP02 model.

Specifications
BTH Andromeda DD03 Pottery Wheel Andromeda DD03
BTH Sirius BP02 Pottery Wheel Sirius BP02
Clay Capacity
60 kg
40 kg
Wheel Head Speed
0–300 rpm
0–300 rpm
Motor Power
400 W
500 W
Noise Level
≤40 dB
≤46 dB
Speed Control
Foot Pedal (Modular)
Hall Effect Pedal
Foot Pedal (Modular)
Hall Effect Pedal
Rotation Direction
Clockwise / Counterclockwise
Clockwise / Counterclockwise
Drive System
Direct Drive
Belt-Pulley
Wheel Head
35.2 cm
Aluminum
31.5 cm
Aluminum
Dimensions
72.5 × 64 × 48–58 cm
68 × 64 × 48–58 cm
Net Weight
37 kg
30 kg
Shipping Weight
46 kg
39 kg
Box Dimensions
80 × 72 × 42 cm
76 × 72 × 48 cm
Bat Pin Spacing
10 inches
10 inches
Acceleration Response
< 1 second
< 1.5 seconds
Deceleration Response
< 2 seconds
< 2.5 seconds
Warranty Period
5 Years
5 Years

BTH Andromeda DD03 is supplied with a 5-year warranty. Its direct drive motor system, high centering capacity, and precise pedal control are designed for professional ceramic production.

BTH
Distributor Warranty
BTH
Brand
BTH
Model
Andromeda DD03
Type
Pedestal
Motor Power
400 W. AC 230V 50Hz
Power Type
220 V (Single-Phase)
Tray Speed
0 - 300 rpm Devir Ayarlı
Tray Diameter
35,2 cm
Tray Material
Aluminium
Clay Carrying Capacity
60 Kg
Rotation Direction
Each Two Direction
Noise Level
≤40 dB
Weight
37 Kg
Packaged Weight
46 Kg
Outer Dimensions (WxDxH)
72.5 x 64 x 48-58 cm
Packaging Size
80 x 72 x 42 cm
Foot Pedal
Available
Pedestals
Detachable
Foot Pedal Portability
Portable with Cable
CE Certification
Certified
Warranty
5 Yıl
